Fill in your serial number to purchase parts for your specific truck bed rack. Part Numbers marked with cannot ship to Canada.

(Located on driver's side rack rail)

Item Part No. Description Price Qty
  Rail Assembly (one utility rail) $130.00 Requires Serial #   Not Available
  10185 3/8" Zinc Plated Flat Washer $1.50
  70346 3/8"-16 Zinc Plated Channel Nut $1.50
  70355 3/8"-18 x 1-1/2" Zinc Plated Serrated Flange Hex Bolt $1.50
  70398 Alignment Plate $2.08
  70406 Clamp Plate $5.20
  4000555 3/8"-16 x 3/4" Zinc Plated Serrated Flange Hex Bolt $1.50
  4000740 Left Rail End Cap $12.50
  4000768 Right Rail End Cap $12.50
  4000770 Black Oxide #8-32 x 3/8" Stainless Steel Phillips Head Screw $1.50
  Left Upright (fits DRIVER side front and PASSENGER side rear) $60.00 Requires Serial #   Not Available
  Right Upright (fits PASSENGER side front and DRIVER side rear) $60.00 Requires Serial #   Not Available
4000778 Cross Bars Assembly (includes decal and top cap) $90.00
4000877 Cross Bar 72" $85.00
  10901 3/8"-18 x 1-1/2" Zinc Plated Serrate Flange Hex Bolt $1.50
  10903 3/8" Zinc Plated Flat Washer $1.50
  30490 Load Divider Top Cap $1.50
  70346 3/8"-16 Zinc Plated Channel Nut $1.50
  4000545 Mounting Bracket $4.00
  4000555 3/8"-16 x 5/8" Serratge Flange Hex Bolt $1.50
  4000783 Cross Bar End Cap $1.50
  4000878 Stabilizing Rubber Cap $8.50
  4000879 Load Divider Body $8.84

Free Shipping on Replacement Parts



Help Section


Watch Installation Videos
Download Install Instructions

The serial number can be found on the driver's side rack rail.

How to Locate Serial Number
